CNC Bending
Sheet metal and tube bending with CNC control to obtain exact angles and high repeatability.
- Plate and sheet bending
- Tube and profile bending
- Structural components
- Supports, cabinets and covers
Service
CNC Bending and Rolling
Precision, Repeatability andQuality in Every Part
We offer CNC bending and CNC rolling for plate, tube and metal components with excellent dimensional finish.
High precision
Repeatability
Quality finishes
Capabilities
CNC BendingCNC RollingPlateTubeProfilesCustom Parts
Our Service
CNC solutions to shape your ideas with precision and efficiency.
CNC Rolling
CNC plate rolling to produce cylinders, cones and uniform radii with excellent finish.
- Plate rolling
- Uniform radii
- Tanks and vessels
- Piping and ducts
Our Machines
High-technology CNC equipment to ensure precision, productivity and versatility.
CNC Bending
CNC Hydraulic Press Brake HS-16032
- Bending capacity: 160 tons
- Maximum bending length: 3,200 mm
- CNC precision (Y axis): ±0.01 mm
- Short-part capacity: 12.7 mm / 0.50"
- Long-part capacity: 6.35 mm / 0.25"
CNC Rolling
CNC 4-Roll Plate Roller W12-16 x 3000
- Max. rolling thickness: 16 mm (carbon steel, σ ≤ 245 MPa)
- Max. rolling width: 3,000 mm
- Usable roll length: 3,100 mm
- Rolling speed: 4 - 5 m/min
- Upper roll diameter: Ø360 mm
- Lower roll diameter: Ø330 mm
- Side roll diameter: Ø250 mm
CNC Tube
CNC Tube Bender M89-5A-3S
- Max. mild-steel outside diameter (OD): ≤ Ø89 x 5.0T
- Max. wall thickness: 4 mm
- Max. bend radius: 15-500 mm (customizable)
- Max. bend angle: 190°
- Feed accuracy: ±0.1 mm
- Max. alignment length: 3,500 mm
Applications
Solutions for a wide variety of industries.
Quality you can see in every part
Controlled processes and high-performance materials for reliable, durable deliveries.
